AutoCAD Tutorial in Hindi | ATTRIBUTE DEFINITION | TOOL PALETTES, Basic to Advanced, Lesson-14

Hey Guys,

Welcome back to the new video of AutoCAD tutorial series in Hindi. In this video you will learn about the Attribute, Edit Attribute and Tool Palettes with its creation for there advanced functionality.
With the help of Attribute Definition we can create Table or Bill of Materials or Title Block as per the require content and we can reuse it in the same drawing or different drawing. We divide this video in 4 parts, which brief topic and time slot is following:-

1. General Overview:- Time(0:40)

In that section you will get to learn about what is attribute and why we use this in various industries. I am explaining this in very simple way with example.

2. Attribute Definition:- Time( 3:17)

Now in that part we come up with main point. i.e how we can apply attribute in drawing. We also see how we can make a Table/Bill of Material/Title Block in very simple way. Main benefit of using attribute is that , we can make a table once and can reuse this every time.

3. Edit Attribute:- Time( 3:17)

In this section we learn about how do we edit our attribute, Because attribute is come into working only when we make it into block and when we make block than we can not edit the object. So, for edit we need to use some external command known as Edit attribute. There are three types of edit attribute:-
1. Attribute Editor
2. Enhance attribute editor
3. Block Attribute Manager

4. Tool Palettes:- Time( 3:17)

In this section we learn about how to make a table or object is reusable for permanent. We can save our object in tool palettes command. Tool palettes is a group of lots of predefined blocks.

To learn about Block in AutoCAD - youtu.be/0RtPeNM4cu0

How to download & install AutoCAD - youtu.be/QIhl7WFvS9Y

To Learn Text and Dimension :- youtu.be/hjWkRMR9uE4
(Annotative vs Standard)
