How to Import DXF in Allegro 17 2 without error
ChannelPCB DESIGNDescription from the creator
downloaded and unpacked your dxf and was able to import it tp allegro with no issues. Here is how I did it :
1 - Select the Design units : MM (we work in MM)
2 - From the file menu select import dxf.
3 - When the dialog box opens click the browse button and select the dxf
4 - Select units : inches (we work in MM)
5 - check incremental addition
6 - click edit/view layers
7 - select the class and sub class you want. (I selected package geometry and assembly top)
8 - click ok, then import
1 - Select the Design units : MM (we work in MM)
2 - From the file menu select import dxf.
3 - When the dialog box opens click the browse button and select the dxf
4 - Select units : inches (we work in MM)
5 - check incremental addition
6 - click edit/view layers
7 - select the class and sub class you want. (I selected package geometry and assembly top)
8 - click ok, then import
