How to pull error codes off a Maytag Bravos washing machine

Please like, subscribe, favorite - it really helps me out a lot.

With power off, ie nothing lit up on machine...
1. 4-5 turns counterclockwise
2. clockwise 1 click, half second pause
3. clockwise 1 click, half second pause
4. clockwise 1 click, half second pause
5. counterclockwise 1 click, half second pause
6. clockwise 1 click
7. all lights should be blinking now - you are in diagnostic mode!
8. turn clockwise till screen reads 02, this is the Automatic Read Mode (there's 9 modes)
9. press start, machine will now quickly test major wash functions
10. beep will note it's done, plus led screen blank, and green light indicating Done. Power off by pressing Power button
11. repeat 1-7, then turn clockwise to 01, the fault code display mode
12. hit start, and turn clockwise one click at a time. each click will give you a code, in order of newest to oldest.
13. go back to CL and press/hold Start for 3 seconds to clear codes.
14. power off

Tips - practice makes perfect. Your speed and pausing time is important. Watch the video a few times to get my pace.

I found a link to a Service Technician Diagnostic Guide, it covers this content, and defines faults codes. It even dives into diagnosing your fault codes further. Pretty cool link. I hope it helps you out.

docs.google.com/file/d/0BzIiBNwRIV4NRzZVN2Y3NGR…

My washer is model MVXW700XW1 Maytag Bravos HE washing machine. It was having issues and making a loud grinding noise during agitation for a while, and then finally just stopped agitating. A sock got caught in the belt and I just cleaned it out, and tightened the pulley wheel. Cleared the codes and away we went.
