ATENA Science GiD Tutorial - Shear Beam - Complete

This video contains step by step description of the nonlinear finite element analysis of a reinforced concrete beam failing by a diagonal shear crack in ATENA software. The example corresponds to the problem described in ATENA Science tutorial manual. The same example is also part of ATENA installation package.

The video shows how to prepare the model in GiD, perform the nonlinear analysis and postprocessing in ATENA Studio, which is the main analysis and postprocessing program in the ATENA simulation system.
- For ease of watch, we have listed the times below wich indicte the beginning of each step
2:15 : Create the points
3:22 : Create the lines
3:59 : Create the surface
4:21 : Create the volume
5:50 : Ceate the loading and supporting plates
9:39 : Create the reinforcements lines
11:58 : Create the layers
13:26 : Define the concrete materials
15:17 : Define the elastic materials
16:01 : Define the reinforcements materials
17:59 : The boundary conditions
24:13 : the loading history (intervals)
25:05 : Create the mesh
27:45 : Running the analysis by ATENA Studio
